APT 150 7.5"x4.5" HF Device
APT:50 Driver with APT:150S Horn
Specifications
Download Spec Sheet| SPECIFICATION | |
| Type | Constant Directivity |
| Throat Size | 1", 25.4mm |
| Dispersion | 100 x 50 |
| Power Rating | 35W (AES) |
| Nominal impedance | 8 Ω |
| Minimum impedance | 7.7 @ 6 kHz |
| Sensitivity | 102.4 dB |
| Resonance | 2.7 kHz |
| Usable Frequency Range | 3500 Hz – 20 kHz |
| Low Rec. Crossover | 3.5 kHz |
| W x H x D (in) | 4.5" x 7.6" x 5.1" |
| W x H x D (mm) | 114.3 x 193 x 129.5mm |
| Cut Out | 6.7 x 3.4 , 170 x 86 mm |
| Weight | 1.9lbs, 0.86kg |
| Material | ABS |
