CannaBass™ CB3010N-8
CannaBass™ CB3010N-8
CannaBass™ CB3010N-8
CannaBass™ CB3010N-8

CannaBass™ CB3010N-8

$231.99
Shipping calculated at checkout.

Product Details

Specifications
Nominal basket diameter
10", 254mm
Nominal impedance
8 Ω
Power rating program power
900 W
Power rating watts
450 W
Resonance
41.62 Hz
Usable frequency range
43 Hz - 3.4 kHz
Sensitivity
94 dB
Gap height
0.365", 9.27 mm
Voice coil diameter
3", 76 mm
Thiele & Small Parameters
Resonant frequency fs
41.62 Hz
Dc resistance re
5.62
Coil inductance le
0.62
Mechanical q qms
7.95
Electromagnetic q qes
0.25
Total q qts
0.25
Compliance equivalent volume vas
55.22 liters, 1.95 cu.ft.
Peak diaphragm displacement volume vd
244.23 cc
Mechanical compliance of suspension cms
0.28 mm/N
Bl product bl
17.22
Diaphragm mass inc airload mms
51.42
Efficiency bandwidth product ebp
163
Maximum linear excursion xmax
6.48 mm
Surface area of cone sd
376.9 cm²
Mounting Information
Recommended enclosure volume sealed
Not Recommended
Recommended enclosure volume vented
Acceptable
Driver volume displaced
0.037 cu.ft. / 1.06 liters
Overall diameter
10.25", 260.35 mm
Baffle hole diameter
9.12", 231.65 mm
Front sealing gasket
Yes
Rear sealing gasket
Yes
Mounting holes diameter
0.28", 7.112mm
Mounting holes b c d
9.73", 247.14mm
Depth
4.25", 108 mm
Net weight
7.1 lbs, 3.22 kg
Shipping weight
8.9 lbs, 4.04 kgs
Materials of Construction
Coil construction
Inside/outside copper
Voice coil former
Fiberglass
Magnet material
Neodymium
Basket material
Die-cast aluminum
Cone composition
Hemp paper
Surround
Cloth
Dust cap composition
Hempylene paper
